If first "Option" is enabled, then steps are buffered.įactor value is speed multiplier in percent If "Distance" is set to 0.01mm and factor is 10, then step is 0.1mm long. If "Distance" is set to 0.01mm and factor is 100, then step is 1mm long. If "Distance" is set to 0.01mm and factor is 1000, then step is 10mm long. If factor value is higher, then you need to turn MPG encoder faster to achieve same speed. If "Distance" is set to 0.01mm and factor is 10, then step is 1mm long.įactor value is set to calculate speed multiplier. If "Distance" is set to 0.01mm and factor is 100, then step is 0.1mm long. If "Distance" is set to 0.01mm and factor is 1000, then step is 0.01mm long. Step distance = "Distance" *(1000 / "Factor") X1 on MPG selects "Mode1", X10 "Mode2" and X100 "Mode3".įor each mode you can set if "Step" mode is enabled.įactor value is used to calculate distance multiplier. Standard MPG pendant has switch for Mode 1, 2 and 3. Seven modes are possible for Mk3 controllers and four modes are possible for Mk2 controller. "Max Speed" is maximum speed that machine can travel when operated with MPG. Enable "Reverse" to set reverse direction. Set "PPR" to your encoder pulses per revolution value. Encoder" to use encoder for measuring spindle RPM. Enable "Invert" option if your signal is active low type.Įnable "Use Rev.

With higher values you can enable fast options to increase response time.

Most common PPR value is one, but you can use higher value. Index" to use index signal for measuring spindle RPM and spindle position. Enable "Reverse" to set reverse MPG direction.Įnable "Use Rev. Most common PPR value for MPG is 100 pulses per revolution. Enable "Invert" option, if your E-Stop switch is active low (NC type).Įnable "Use MPG" to use MPG pendant.

#CNC USB CONTROLLER MK3 9 AXIS REGISTRATION#

– activate software using your license – open the “License Activation” dialog and paste your registration key.Enable "E-Stop" to use E-Stop switch connected to CTRL1 pin.

#CNC USB CONTROLLER MK3 9 AXIS INSTALL#

– download and install the latest software

110 kHz maximum step frequency, 25 us pulse width, 50% duty cycle at higher frequencies.

integrated web server for monitoring state and sending commands.

sensor for capturing and measuring digitizing probe support.

control external devices with I2C and UART protocol.

SD card support for running g-code without computer.

spindle encoder and index signal support for spindle synchronization.

additional inputs with add on boards (currently up to 32).

8 digital inputs onboard, filtered, and protected.

8 limit switch inputs with shift feature.

jogging keyboard support with speed potentiometer, shift, step, and spindle sync feature.

additional outputs with add on boards (currently up to 32).

3 outputs with support for RC servo motors.

3 PWM capable outputs with selectable frequency (10Hz to 500kHz).

9 axes controller for stepper and servo motors.

#CNC USB CONTROLLER MK3 9 AXIS DRIVERS#

Please note: This is a USB and Ethernet breakout board that allows you to control stepper drivers using special Planet CNC TNG software and Stepper Motor Drivers will be needed to run the motors. It can be used as a direct replacement for many parallel port break-out boards. It has the same pinout as popular PICStep and PMinMO drivers. The CNC USB Controller is compatible with most step/dir drivers. The CNC USB Controller is the Complete Hardware and Software Solution! This is a CNC Controller board used for controlling your CNC Machine. Description CNC USB Controller Mk3 The Complete Hardware and Software Solution!
